Dosatron 26gpm Injector D6mz2vfii 0.2-2.0% With Bypass
Quick answer
Dosatron 26gpm Injector D6mz2vfii 0.2-2.0% With Bypass should be matched by flow rate, pressure, line size, fitting type, filtration, and the number of plants or zones being fed.
Shopping guidance from Toledo Indoor Garden. Prices, availability, shipping rates, weights, and dimensions are verified during checkout.
Description
The Dosatron D6MZ2 is a high-flow water-powered chemical injector designed for large greenhouse, nursery, and commercial growing operations requiring flow rates up to 26 GPM.
Features inlet injection technology for enhanced mixing consistency.
Key Specifications: • Flow Rate: 0.44–26 GPM (1.7–98 LPM) • Injection Ratio: 1:500 to 1:50 (0.2%–2%) • Operating Pressure: 4.3–116 PSI (0.3–8 bar) • Connection Size: 1-1/4" NPT • Housing Material: Polypropylene • Seal Material: Viton (acidic chemistry compatible) • Dimensions: 25" x 9" x 8" Included: Mounting bracket, 6' clear suction tube, weighted strainer, bypass valve, and quick start guide.
Compatible With: Fertilizers, pH adjusters, sanitizers, fungicides, pesticides.
Replaces the older D45-20 GPM injector with higher pressure tolerance and increased flow capacity.
Features: High-performance locking ring prevents misalignment of dosing settings.
Internal motor sleeve facilitates easy servicing.
Water-powered — no electricity required.
Verify tubing size, connection type, pressure range, flow rate, reservoir layout, and replacement-part compatibility before adding it to an irrigation build.
Weight: 8 lbs.
Dimensions: 25 x 9 x 8 in.
- Valve
- Genuine Dosatron product
- Brand: Dosatron
- Category: Hydroponics & Irrigation > Dosers & Injectors
- Listed weight: 8 lbs
- Listed dimensions: 25 x 9 x 8 in
