Dosatron
Dosatron Water Powered Doser 14 GPM 1:100 to 1:10, 3/4 in
SKU: DS14GPMRAT
$1,485.99
Out of Stock
Trusted Since 2009
Quick answer
Dosatron Water Powered Doser 14 GPM 1:100 to 1:10, 3/4 in should be matched by flow rate, pressure, line size, fitting type, filtration, and the number of plants or zones being fed.
Best fitIrrigation or hydroponic systems where pumps, tubing, fittings, filters, and emitters need to work together.
Check before orderingConfirm thread size, tubing ID/OD, fitting type, pressure needs, filtration, and timer compatibility.
Grower tipBuild irrigation with serviceability in mind. Filters, shutoffs, and spare fittings save time when a room is full.
Shopping guidance from Toledo Indoor Garden. Prices, availability, shipping rates, weights, and dimensions are verified during checkout.
Description
Dosatron Water Powered Doser 14 GPM 1:100 to 1:10 - 3/4 in (D14MZ10VFBPHY)
The Dosatron water powered doser inject nutrients, supplements/additives and pH adjusters into irrigation water with ease. Dosatron is a passive precision fertilizer doser that accurately mixes from the pressure of your incoming water (no electricity needed). The water pressure forces the solution downstream. Operating pressure range is 7 -85 PSI and water flow range is 0.05 - 14 GPM. Injection capabilities of 1:100 to 1:10 (1 to 10%) [1.280 to 12.800 ounces per gallon]. Unit has 3/4 in NPT connections. Includes mounting bracket, suction hose, bypass, union, weighted strainer, and quick start guide. Mini-maintenance seal kit for Dosatron Dosers - should be replaced on an annual basis.
The Dosatron water powered doser inject nutrients, supplements/additives and pH adjusters into irrigation water with ease. Dosatron is a passive precision fertilizer doser that accurately mixes from the pressure of your incoming water (no electricity needed). The water pressure forces the solution downstream. Operating pressure range is 7 -85 PSI and water flow range is 0.05 - 14 GPM. Injection capabilities of 1:100 to 1:10 (1 to 10%) [1.280 to 12.800 ounces per gallon]. Unit has 3/4 in NPT connections. Includes mounting bracket, suction hose, bypass, union, weighted strainer, and quick start guide. Mini-maintenance seal kit for Dosatron Dosers - should be replaced on an annual basis.
- Tubing
- Genuine Dosatron product
- Brand: Dosatron
- Category: Hydroponics & Irrigation > Dosers & Injectors
- Listed weight: 6 lbs
- Listed dimensions: 23 x 9 x 7 in
Specifications
SKUDS14GPMRAT
BrandDosatron
UPC849969009187
Weight6.00 lbs
Dimensions23 x 9 x 7 in
Sold Aseach
TypeTubing
GPM14 GPM
Size3/4"
Thread Size3/4 NPT
Pressure85 PSI
TypeWater-Powered Chemical Injector
Flow Rate Gpm14 GPM
Injection Ratio1:100 to 1:10
Connection Size3/4"
Seal TypeViton
Pressure Range7–85 PSI
Power SourceWater pressure (no electricity)
Bypass SwitchYes
