ThinkGrow
ThinkGrow OPA-2 Smart Junction Box
SKU: TRCOPA2
$230.00
Out of Stock
Quick answer
ThinkGrow OPA-2 Smart Junction Box should be matched to canopy footprint, mounting height, dimming needs, crop stage, heat load, and controller compatibility.
Best fitGrow spaces where the fixture footprint, power draw, and hanging height fit the actual canopy.
Check before orderingConfirm voltage, plug type, controller compatibility, dimensions, hanging hardware, and room heat management.
Grower tipStart with conservative intensity, then raise output as plants respond. Airflow and distance matter as much as wattage.
Shopping guidance from Toledo Indoor Garden. Prices, availability, shipping rates, weights, and dimensions are verified during checkout.
Description
(OPA-2) Smart Junction Box
The ThinkGrow Smart Junction Box 2 (OPA-2) is an electronic circuit breaker and energy meter designed for real-time monitoring and control of electrical parameters such as voltage, current, power, and power factor. Equipped with overcurrent protection functionality, users can set three levels of overcurrent protection points. With built-in overcurrent protection and compatibility with TrolMaster controllers, the OPA-2 allows remote monitoring and adjustment of settings for optimal performance.
The OPA-2 allows users to set parameter values for Line 1 and Line 2 in Light Group Control Groups 0-9, as well as for UV, White, Deep Red, and Far Red in Spectrum Group Groups 0-9. This functionality enables precise control over the illumination levels of the lighting strips Featuring RS-485 communication, it supports precise control of lighting systems and offers unparalleled reliability and durability. If the circuit protector detects unusually high amperage, the power to the LEDs will be turned off to prevent damage to the LEDs and the Daisy Chain Power Cord System.
Features & Benefits
Package Contents
The ThinkGrow Smart Junction Box 2 (OPA-2) is an electronic circuit breaker and energy meter designed for real-time monitoring and control of electrical parameters such as voltage, current, power, and power factor. Equipped with overcurrent protection functionality, users can set three levels of overcurrent protection points. With built-in overcurrent protection and compatibility with TrolMaster controllers, the OPA-2 allows remote monitoring and adjustment of settings for optimal performance.
The OPA-2 allows users to set parameter values for Line 1 and Line 2 in Light Group Control Groups 0-9, as well as for UV, White, Deep Red, and Far Red in Spectrum Group Groups 0-9. This functionality enables precise control over the illumination levels of the lighting strips Featuring RS-485 communication, it supports precise control of lighting systems and offers unparalleled reliability and durability. If the circuit protector detects unusually high amperage, the power to the LEDs will be turned off to prevent damage to the LEDs and the Daisy Chain Power Cord System.
Features & Benefits
- Lighting fixture Grouping
- Complete power-off solution for night cycle
- Overcurrent Protection
- Power Surge Protection
- Power Consumption Data Collection
- On-Site Monitoring
Package Contents
- 1 x Smart Junction Box (OPA-2)
- 1 x ThinkGrow 12' Daisy Chain Control Cable (ECS-7)
- 2 x 12ft RJ12 to 4-Pin IP65 Connector Cable (ECS-9)
- 2 x Y- Splitter
- Input Voltage: 100-277V~, 50/60Hz
- Rated Current: 30A
- Rated Voltage: 100-277V~
- Shut-off Point Range: 15A / 20A / 30A
- Sensitivity to Protection: Response within 0.5s
- Overcurrent Protection Point: +120%
- Temperature: 32-104°F (0-40°C)
- Humidity: ≤90%
- Genuine ThinkGrow product
- Brand: ThinkGrow
- Category: Grow Lights > Light Accessories
- Listed weight: 3.79 lbs
- Listed dimensions: 14 x 10 x 7 in
- Review product photos, selected option, specifications, and label directions before ordering
Specifications
SKUTRCOPA2
BrandThinkGrow
UPC6970207972971
Weight3.79 lbs
Dimensions14 x 10 x 7 in
FunctionElectronic circuit breaker + energy meter
MonitoringReal-time voltage, current, power, power factor
Overcurrent Protection3 adjustable levels
Spectrum Group ControlGroups 0-9 for UV, White, Deep Red, Far Red
Light Group ControlGroups 0-9 for Line 1 and Line 2
Compatible FixturesThinkGrow Model-I, Model-I Plus, ICL series
Warranty5 Years
ColorWhite
